Quick find code: 111134

Model no: CSW0501V3

Key Features

The 18Gbps 4K 60Hz  CSW0501V3 enables you to connect 5 HDMI input to 1 display. You can  change HD inputs using the included IR remote or physical buttons on the unit itself.

Supported video resolution is up to 4K2K@50/ 60Hz YCbCr 4:4:4. It supports HDR, HDR10, Dolby Vision and HLG. It supports all 3D video formats.

• 18Gbps 4K 60Hz HDMI Switch 5 X 1 (5 inputs 1 output)
• 5x HDMI (female) inputs
• 1x HDMI (female) output
• HDMI: 2.0, 1.4
• HDCP: 2.2, 1.4
• HDMI Bandwidth: 18Gbps
• HDMI Inputs: 5
• HDMI Output: 1
• IR Port: 1 IR Receiver port
• supports video formats up to 4Kx2K@60 and all HDMI 3D video formats
• Support input port auto switching or manual switching mode
• Easy to install – Simple plug & play operation
• UK Power Supply included
• Size: 90mm X 60mm X 19mm
• Perfect for:  Cable Box, Roku, Apple TV, Blu-ray Player, Nintendo Switch, Xbox One X, PS4 Pro,PS3, HD DVD, Xbox 360 Elite, Apple TV, Virgin V+, Sky HD, Freesat HD, Blu-ray Disc, DVD, HD Camcorder, HTPC, Laptop

What's in the box?

• 1 X CSW0501V3 18Gbps 4K 60Hz HDMI 5X1 Switcher with Remote (5 way input 1 output)
• 1 X  UK 5V USB Power Cable
• 1 X  IR Receiver Cable
• 1 X Remote Control
• 1 X User Manual
